Type: Digital, AF/AE single-lens reflex camera, Recording Media, Dual CF Cards (Type I or II)Compatible with UDMA 7 CF cards, Image Format, Approx. 36 mm x 24mm (35 mm Full-frame), Compatible Lenses, Canon EF Lenses, Lens Mount, Canon EF mount, Image Sensor, Type, High-sensitivity, high-resolution, large single-plate CMOS sensor, Pixels, Effective pixels: Approx. 18.1 megapixels, Total Pixels, 19.3 megapixels, Aspect Ratio, 3:2 (Horizontal:Vertical), Color Filter System, RGB primary color filters, Low Pass Filter, Fixed position in front of the image sensor, Dust Deletion Feature, (1) Self Cleaning Sensor Unit, Carrier wave type Removes dust adhering to the infrared- and ultraviolet-blocking glass. Self-cleaning executed automatically (taking about 1.8 sec.) when power is turned on or off. Manual execution also possible (taking about 5.2 sec.). Low-pass filter has a fluorine coating.(2) Dust Delete Data acquisition and appending. The coordinates of the dust adhering to the infrared- and ultraviolet-blocking glass are detected by a test shot and appended to subsequent images. The dust coordinate data appended to the image is used by the provided software to automatically erase the dust spots.(3) Manual cleaning.
Recording System: Recording Format: Design Rule for Camera File System 2.0 and EXIF 2.3 Image Format, Still Image: JPEG,
RAW (14-bit Canon Original), M-RAW, S-RAW, RAW+JPEG, M-RAW+JPEG, S-RAW+JPEG, Video:
MOV (Image data: H.264; Audio: Linear PCM), File Size (1) Large: Approx. 17.9
Megapixels (5184 x 3456), (2) M1: Approx. 14.20 Megapixels (4608 x 3072), (3)
M2: Approx. 8.00 Megapixels (3456 x 2304), (4) Small: Approx. 4.5 Megapixels
(2592 x 1728), (5) RAW: Approx. 17.90 Megapixels (5184 x 3456), (6) M-RAW:
Approx. 10.10 Megapixels (3888 x 2592), (7) S-RAW: Approx. 4.50 Megapixels
(2592 x 1728), Exact file sizes depend on the subject, ISO speed, Picture
Style, etc. Recording Functions: 1. Standard Select one of the CF cards to
record., 2. Auto switch card, When the current card becomes full, the camera switches
to the other card automatically. 3. Record separately, The same image is saved
to both cards, but in a different size (L, M1, M2, S, RAW, M-RAW, or S-RAW)
that was set for the respective card. 4. Record to multiple, The same image is
saved to both cards in the same size (RAW+JPEG also possible).
Backup Recording: N/A, File
Numbering, Consecutive numbering,
auto reset, manual reset. Possible to create new folders
and select folders in the CF card, RAW + JPEG Simultaneous Recording, The
image-recording quality can be selected in any combination of the three RAW and
four JPEG recording quality settings. Color Space, sRGB, Adobe RGB, Picture
Style, Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User
Defined 1-3, White Balance, Settings, Auto, Daylight, Shade, Cloudy, Tungsten
Light, White Fluorescent Light, Flash, Custom, Color Temperature setting, Auto
White Balance, Auto white balance with the image sensor, Color Temperature
Compensation, Blue/amber bias: ±9 levels, Magenta/green bias: ±9 levels, *Corrected
in reference to the current WB mode's color temperature. Color Temperature
Information Transmission, Provided, Viewfinder, Type, Eye-level pentaprism Coverage.
Vertical/Horizontal approx. 100%. Magnification: Approx. 0.76x (-1m-1 with 50mm
lens at infinity) / 35.0° angle of view, Eye Point, Approx. 20mm (At -1m-1 from
eyepiece lens center), Dioptric Adjustment Correction, -3.0 to +1.0 m-1
(diopter), Focusing Screen Interchangeable, Mirror, Quick-return half mirror
(transmission: reflectance ratio of 40:60) Viewfinder Information, - AF
information (AF point, focus confirmation, AF status indicator) Exposure information (Metering
mode, shooting mode, AE lock, shutter speed, aperture, exposure compensation,
ISO speed (always displayed), exposure level, exposure warning) Flash
information (Flash ready, high-speed sync, FE lock, flash exposure
compensation) Image information (White balance correction, highlight-tone
priority (D+), maximum burst(2-digit display), CF card information, JPEG/RAW
indicator), Battery check, Composition information (Grid, electronic level), Depth
Of Field Preview, Enabled with depth-of-field preview button.
Autofocus: Type: TTL-AREA-SIR
AF-dedicated CMOS sensor, AF Points, 61-point AF - One to five cross-type AF points at f/2.8, 10 to 20 cross-type
AF points at f/4, and 15 to 21 cross-type AF points at f/5.6. 1 cross-type AF
point at f/8.* (The number of cross-type AF points will differ depending on the
lens.), - With Firmware Version 1.1.1
installed., Focusing Modes, (1)
Autofocus, One-Shot AF, Predictive AI Servo AF, For automatic AF point selection, the
AF point to start the AI Servo AF operation can be selected. For automatic AF
point selection, the active AF point can be displayed., AI Focus AF (Switches between One-Shot AF and AI SERVO AF
automatically), (2) Manual focus
(MF), AF Point Selection, 1. Single-point AF (Manual selection), 2. Auto selection 61-point AF, 3. Single-point Spot AF (Manual
selection), 4. AF point expansion
(Manual selection, 4 points: up, down, left, and right). Firmware Ver. 1.1.1
allows cross-type autofocusing with the center AF point up to a maximum
aperture of f/8 when using an extender. When AF point expansion is used with a
lens/extender combination, the four AF points surrounding the center point act
as AF assist points. Points above and below are sensitive to vertical contrast,
while those to the left and right are sensitive to horizontal contrast, 5. AF point expansion (Manual
selection, surrounding 8 points). 6.
Zone AF (Manual zone selection), AF Function Registration/Switching. With a Custom Function, four types of
AF function settings can be registered in a group: 1. AF area selection mode,
2. AI Servo tracking sensitivity, 3. AI Servo AF tracking method, and 4. AI
Servo 1st/2nd img priority. This function can be assigned to the
depth-of-field preview button or lens A stop button by customizing camera
controls/buttons (Custom Controls). Selected AF Point Display, Indicated by
transmissive LCD display in the viewfinder and on the LCD panel.
Active AF Point Indicator: AF Area and AF Point Selection, From the Orientation Linked AF Point
menu, the AF area and manually-selectable AF point can be set separately for
horizontal and vertical (camera grip at the top or bottom) shooting. AF Point Illumination during AI Servo
AF, With Firmware Ver. 1.1.1, AF
points can be illuminated in red with a half-press of the shutter button in AI
Servo AF mode. Illumination is intermittent, not continuous, and does not
interfere with metering accuracy. AF
Assist Beam, When an external
EOS-dedicated Speedlite is attached to the camera, the AF-assist beam from the
Speedlite will be emitted when necessary.
Exposure Control, Metering Modes. 252-zone metering with approx.
100,000-pixel RGB AE sensor and TTL maximum aperture metering employed. The
following metering modes selectable: (1)
Evaluative metering (linked to all AF points), (2) Partial metering (center, approx. TBA% of viewfinder), (3) Spot metering (center, approx.
TBA% of viewfinder), 1. Center spot
metering, 2. AF point-linked spot
metering (Custom Function) Linkable
to all AF points. With automatic AF
point selection, center spot metering is set. 3. Multi-spot metering, Up to eight multi-spot meter readings can
be taken. (4) Center-weighted
average metering, 1. The selectable metering modes can be restricted with a
Custom Function. Metering Range, EV
0 - EV 20 (at 73°F/23°C with 50mm f/1.4 lens, ISO 100), Exposure Control Systems. Program
AE (Shiftable), Shutter-priority AE, Aperture-priority AE, Manual exposure,
Bulb, E-TTL II autoflash program AE, ISO
Speed Range, Automatically set, ISO
100-51200 (in 1/3-stop or 1-stop increments) Basic Zone modes: ISO 100-51200 set automatically Extension
settable: ISO 50; 102,400 and 204,800.
Super High-speed: Maximum 14 shots/sec. High-speed: Maximum 12
shots/sec. Low-speed: Maximum 3 shots/sec. Maximum Burst, The maximum burst
during continuous shooting is as follows: JPEG Large: Approx: TBA, UDMA CF
Card: Approx: TBA, RAW: Approx: TBA, UDMA 7 CF Card: Approx. TBA, Live View
Functions, Shooting Modes, Still photo and video recording Focusing, Quick mode (61- Point
Phase-difference detection AF), Live mode/Face detection Live mode (One-Point
Contrast detection AF, switching to another point possible), Face detection
Live mode (Contrast AF, Face Selectable), Manual focusing (5x/10x magnification
possible), Metering Modes, Real-time Evaluative metering with the image sensor,
Metering Range, Real-time evaluative metering with image sensor:Metering range:
EV 0 - EV 20 (At 73°F/23°C, 50mm f/1.4 lens, ISO 100)AE lock possible The
active metering time can be changed. Grid Display, Three grid display provided,
Exposure Simulation, Possible, Silent Shooting, Provided, Video Shooting, File
Format, MOV (image data: H.264; audio: Linear PCM)Internal monaural microphone
External stereo microphone jack available, File Size, Recording Sizes: 1920 x
1080 (Full HD), 1280 x 720 and 640 x 480, Frame Rates, [1920 x 1080]: 30 fps /
25 fps / 24 fps, [1280 x 720]: 60 fps / 50 fps, [640 x 480]: 30 fps / 25 fps, Continuous
Shooting Time, Recording Times based on 8 GB Memory Card: [1920 x 1080], 30
fps: ALL-I (TBA) / IPB (TBA), 25 fps ALL-I (TBA) / IPB (TBA), 24 fps ALLI-I
(TBA) / IPB (TBA), [1280 x 720], 60 fps: ALL-I (TBA) / IPB (TBA), 50 fps ALL-I
(TBA) / IPB (TBA), [640 x 480], 30 fps: IPB (TBA), 25 fps: IPB (TBA).
Focusing: Same as Live View Shooting, Exposure Control, Program
AE, Manual exposure Exposure
Compensation, ±3 stops in 1/3- or
1/2-stop increments, LCD Monitor, Type, TFT color, liquid-crystal monitor, Monitor Size, 3.2-inches. Pixels, Approx. 1.04 million dots, Coverage, Approx. 100%, Viewing angle: 170°, Brightness Control, 7 levels provided, Interface Languages, 25
(English, German, French, Dutch, Danish, Portuguese, Finnish, Italian,
Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian,
Romanian, Ukraine, Turkish, Arabic, Thai, Simplified/Traditional Chinese,
Korean, Japanese), Playback, Display Format, Single image, Single image + Image-recording quality/shooting
information, histogram, 4- or 9-image index, magnified view (approx. 1.5x-10x),
rotated image (auto/manual), image jump (by 10/100 images, index screen, by
shooting date, by folder), slide show (all images/selected by date/folder),
star rating, Highlight Alert, With single-image display (Info.) and
single-image display, overexposed highlight areas will blink, Image Protection and Erase, Protection, Erase protection can be applied or canceled for a single image,
all images in a folder or all images in the card. Erase: Erase a single
image, selected images, all images in a folder, all images in a card or erase
only unprotected images, Direct
Printing: Compatible Printers, PictBridge-compatible printers, Printable Images, RAW and JPEG images complying to Design rule for Camera File
System, Movies cannot be printed. DPOF: Digital Print Order Format, DPOF, Version 1.1 compatible, Direct Image Transfer Compatible Images, JPEG and RAW images
and movies For RAW+JPEG, only the RAW or JPEG image or both images can be
transferred.
Camera User Settings: Current camera settings can be registered to
C1, C2 and C3 on the Mode Dial (Automatic registration update is possible), My Menu Registration, Up to six
top-tier menu options and Custom Function settings can be registered, Interface, USB Terminal For personal computer
communication and direct printing (USB 2.0 Hi-Speed), Video Out Terminal, (1)
Video OUT terminal: NTSC/PAL selectable, (2) mini-HDMI OUT terminal, Extension
System Terminal, For connection to WFT-E6A (WFT) and GP-E1 (GPS), Power Source Battery, One Battery Pack LP-E4N
or LP-E4, AC power can be supplied with the AC Adapter Kit ACK-E4, Number of
Shots, Number of shots (approx.), The figures above are based on CIPA (Camera
& Imaging Products Association) testing standards, Battery Check, Automatic
battery check when the power switch is turned on: Displayed in 6 levels:Battery
level displayed on LCD panel and in viewfinder. Battery information can be
checked with the [Battery info.] menu, Power Saving, Power turns off after the
set time (1, 2, 4, 8, 15 or 30 minutes) of non-operation elapses. Date/Time
Battery, CR2025 lithium battery, Start-up Time, Approx. 0.1 sec Dimensions and Weight, Dimensions
(W x H x D), Approx. 158 x 163.6 x 82.7 mm / 6.2 x 6.4 x 3.3 in. Weight, Approx.
1530 g / 54.0 oz. Operating Environment, Working Temperature Range, 32-104°F/0-40°C,
Working Humidity Range, 85% or less. EOS-1D
X Digital SLR Body-Eyecup Eg (not shown)Battery Pack LP-E4NBattery Charger
LC-E4NWide Neck Strap L7Cable Protector Stereo AV Cable AVC-DC400ST USB
Interface Cable IFC-200UEOS Digital Solution Disc-Software Instruction Manual.
