Image Sensor: Type: 22.3
x 14.9mm CMOS. Effective Pixels: Approx.
24.2 megapixels. Total Pixels: Approx.
25.8 megapixels. Aspect Ratio: 3:2. Low-Pass Filter: Built-in/Fixed. Sensor Cleaning: EOS integrated
cleaning system. Color Filter Type: Primary
Color. Image Processor: Type: DIGIC
7. Lens: Lens Mount. EF-M (EF and EF-S lenses compatible
via Mount adapter EF-EOS M). Focal Length: Equivalent to 1.6x the focal length
of the lens. Image Stabilization: Optical Image Stabilizer on compatible lens. Movie: In-camera 5-axis Digital IS
available.
Further stabilization enhancements from lenses compatible with
Dynamic IS. Focusing: Type: Dual Pixel
CMOS AF System. Phase detection pixels
built onto imaging sensor. AF System/ Points: Maximum 49 AF points (Fixed
location on 7x7 grid) via camera automatic selection, freely position 1 AF
point/ 1 AF Zone (9 points, 3x3 grid) via manual selection. AF working range: EV
-1 - 18 (at 23 °C, ISO 100, with EF-M 22mm f/2 STM). AF Modes: One-Shot AF and Servo AF. AF Point Selection: Face + Tracking: Face and subject tracking
via automatic recognition/ manual selection via touchscreen. Automatic
selection over 49 AF points when no face recognized within frame. Smooth Zone
AF: Manual zone selection, plus automatic selection over 9 AF points within
selected zone. 1-point AF: Manual selection via touchscreen/ buttons. Selected AF point display: Indicated
on LCD monitor/ EVF.
AF Lock: Locked when
Shutter Button is pressed half way or customizable AE Lock Button. AF Assist Beam: via LED assist beam. Manual
Focus: With EF & EF-S lenses - Select via AF/MF switch on lens. With EF-M
lenses - Select via dedicated MF Button/ other customizable buttons (toggle
AF/MF). MF Peaking available. AF+MF available (Manual focus adjustment after
One-Shot AF). Magnify image available during MF (5x or 10x). Exposure Control: Metering modes. Real-time metering from the image sensor. (1) Evaluative
metering. (2) Partial metering at
center. (3) Center weighted average metering.
(4) Spot metering. Metering Range: EV
1-20 (at 23 °C, ISO 100). AE Lock: Auto:
In One-shot AF mode with evaluative metering exposure is locked when focus is
achieved. Manual: By AE Lock Button in
creative zone modes. Exposure
Compensation: +/-3 EV in 1/3 stop increments. AEB: 3 shots, +/- 2 EV, 1/3-stop increments (can be used together
with manual Exposure Compensation). ISO
Sensitivity: ISO AUTO (100 - 25600), 100 - 25600 in 1/3 stop increments. Movie:
ISO AUTO (100-6400), 100-6400 in 1/3-stop increments. Shutter: Type: Electronically controlled focal-place shutter. Speed: 30-1/4000 sec (1/3 stop
increments), Bulb (Total shutter speed range. Available range varies by
shooting mode).
White Balance: Type: Auto
white balance with the imaging sensor. Settings:
AWB, Daylight, Shade, Cloudy, Tungsten light, White. Fluorescent light, Flash, Custom, Color Temperature (100 Kelvin
increments). White balance compensation: 1. Blue/Amber +/-9 levels. 2. Magenta/ Green +/-9 levels. Custom White Balance: Yes, 1 setting
can be registered. LCD Monitor: Type:
8.0 cm (3.2”) ClearView II Touchscreen LCD (TFT). 3:2 aspect ratio. Approx.
1,620,000 dots. Electrostatic capacitive type. Tiltable 85 degrees up and 180
degrees down. Coverage: Approx. 100%. Brightness Adjustment: Adjustable to
one of five levels. Display Options: Customizable and toggle via INFO. Button.
(1)
Live view image with basic info. (2) Live view image with full info. (3) Live
view image with no information. (4) Quick Control Screen. Customizable
settings: Grid overlay (x3 formats), Histogram (Brightness/ RGB), Electronic
Level, Multi aspect ratios. Storage:SD, SDHC, SDXC (UHS-I compatible). PowerSource: Batteries: 1 x Rechargeable Li-ion Battery LP-E17. Battery life: With
LCD monitor: Approx. 295 shots (at 23 °C, AE 50%, FE 50%). With EVF: Approx. 295 shots (at 23 °C, AE 50%,
FE 50%). ECO Mode: Approx. 420 shots (at 23 °C, AE 50%, FE 50%). Battery
Indicator: 4 levels. Power saving: Display off (15, 30 sec or 1, 3, 5, 10, 30
mins). Auto Power Down (30 sec or 1, 3, 5, 10 mins), ECO mode. Power Supply
& Battery Chargers: Battery charger LC-E17. Compact Power Adapter CA-PS700.
DC Coupler DR-E17.
